ACEMAGIC F5A Mini PC Gets Ryzen AI HX 470 Spec Bump

The ACEMAGIC F5A AI 470 represents a modest but meaningful upgrade to the company's mini PC lineup, bringing AMD's latest Ryzen AI HX 470 processor to the compact form factor that made the previous model popular. While the changes might seem incremental on paper, they offer tangible performance improvements for users who need more processing power in a small package.

Processor Upgrade: From HX 370 to HX 470

The most significant change in the new ACEMAGIC F5A AI 470 is the processor upgrade from the AMD Ryzen AI 9 HX 370 "Strix Point" to the Ryzen AI 9 HX 470 "Gorgon Point." These chips belong to the same family but have notable differences in their capabilities:

The Ryzen AI 9 HX 470 features a maximum CPU boost speed of 5.1 GHz, compared to 5 GHz in the HX 370. The GPU also receives a boost, with a maximum speed of 3.1 GHz versus 2.9 GHz in the previous model. The Neural Processing Unit (NPU) has been upgraded as well, delivering up to 55 TOPS (trillion operations per second) of AI performance, up from 50 TOPS in the HX 370.

While these numbers might seem modest, synthetic benchmarks indicate that the new chip delivers approximately 9% better multi-core CPU performance and a 7.5% boost in single-core performance. For applications that can leverage these improvements, this translates to noticeable gains in productivity and responsiveness.

AMD emphasizes the AI capabilities of these processors, noting that the Ryzen AI 9 HX 470 delivers up to 86 TOPS of total on-device AI processing power when combining the NPU, GPU, and CPU. This represents a 6% increase over the 80 TOPS offered by the HX 370, making the new model particularly attractive for AI workloads, machine learning tasks, and other applications that benefit from dedicated AI acceleration.

Memory Configuration Options

ACEMAGIC has taken an interesting approach with memory options in the new F5A AI 470, offering two distinct paths for users:

1. The barebones configuration maintains two SODIMM slots for user-upgradeable DDR5-5600 memory, just like its predecessor. This option provides flexibility for users who want to customize their memory configuration or upgrade in the future.

2. New to this generation is the availability of pre-configured models with 32GB of LPDDR5x-8000 onboard memory. This memory type offers several advantages over traditional DDR5:

   • Higher bandwidth for improved performance
   • More power efficiency, extending battery life in mobile scenarios
   • Smaller physical footprint, contributing to the compact design

However, the LPDDR5x memory is soldered to the mainboard, making it non-user-replaceable. Users who choose this configuration will need to select their desired memory capacity at purchase time.

The pre-configured models with LPDDR5x memory also come with a 1TB PCIe 4.0 x4 NVMe SSD pre-installed and carry a significantly higher price tag of $1299, compared to the $759 barebones model. This represents a substantial premium for the convenience and performance benefits of the soldered memory.

Storage Configuration Considerations

The storage configuration has also seen some changes between the generations. While the barebones models maintain the same storage capabilities as before, the pre-configured models with LPDDR5x memory now offer three M.2 slots instead of two. However, this isn't a straightforward upgrade, as the configuration differs:

• The previous model had two PCIe 4.0 x4 slots
• The new model has one PCIe 4.0 x4 slot and two PCIe 4.0 x2 slots

This change means that while users get more physical slots, the bandwidth available to each slot is reduced. For users who need maximum performance from multiple high-speed drives, this could be a consideration.

Connectivity and Ports

One area where the ACEMAGIC F5A AI 470 maintains consistency with its predecessor is in its extensive connectivity options. The mini PC comes with a comprehensive set of ports that make it versatile for various use cases:

• 1 x OCuLink (64 Gbps) - Provides an external PCIe 4.0 x4 connection for graphics docks or other high-speed peripherals
• 2 x USB4 Type-C (40 Gbps with DisplayPort Alt Mode, 15W power output, 100W power input)
• 3 x USB 3.2 Gen 2 Type-A (10 Gbps)
• 1 x USB 2.0 Type-A (480 Mbps)
• 1 x HDMI 2.1
• 1 x DisplayPort 2.1
• 2 x 2.5 GbE LAN
• 1 x 3.5mm audio
• 1 x DC power input

This extensive port selection ensures that users can connect multiple displays, high-speed storage devices, networking equipment, and various peripherals without needing additional dongles or hubs.

Physical Design and Cooling

The ACEMAGIC F5A AI 470 maintains the compact form factor that defines the mini PC category, measuring just 130 x 132 x 62mm. Despite its small size, the device includes dual fans and an aluminum cooling plate to help manage thermals, particularly important when running the more powerful Ryzen AI HX 470 processor.

The compact design makes it suitable for various applications, including:

• Home theater PCs
• Desktop replacements
• Development workstations
• Digital signage
• Industrial applications where space is at a premium

Pricing and Value Proposition

The ACEMAGIC F5A AI 470 is priced at $759 for the barebones configuration, representing a $30 premium over the current price of the F5A AI 370 ($729). For users who need the additional performance of the Ryzen AI HX 470, this modest increase could be justified by the improved CPU and GPU performance, as well as the enhanced AI capabilities.

The pre-configured model with 32GB of LPDDR5x-8000 memory and a 1TB SSD carries a list price of $1299, which represents a significant premium over the barebones option. While this configuration offers the convenience of pre-installed memory and storage, as well as the performance benefits of LPDDR5x, the price point might be prohibitive for many users who would be better served by purchasing the barebones model and adding their own memory and storage.

Market Position and Competition

In the increasingly crowded mini PC market, the ACEMAGIC F5A AI 470 positions itself as a compact yet powerful solution that doesn't compromise on connectivity or expandability. The inclusion of features like WiFi 7, Bluetooth 5.4, and the extensive port selection ensures that it remains competitive with other mini PCs in its price range.

The Ryzen AI HX 470 processor gives it an edge in AI workloads compared to mini PCs with less powerful processors, making it suitable for applications like:

• AI development and testing
• Machine learning inference
• Content creation with AI-assisted tools
• Virtual desktop infrastructure (VDI) with AI acceleration

Conclusion

The ACEMAGIC F5A AI 470 represents a thoughtful evolution of the previous model, bringing meaningful performance improvements while maintaining the compact design and extensive connectivity that made the original popular. The processor upgrade offers tangible benefits for compute-intensive and AI workloads, while the memory configuration options provide flexibility for different user needs.

While the price increase is modest for the barebones model, the premium for the pre-configured LPDDR5x version is significant, potentially limiting its appeal to users who prioritize convenience over cost. For most users, the barebones configuration with user-upgradeable DDR5 memory likely offers the best balance of price, performance, and flexibility.

As mini PCs continue to gain popularity as alternatives to traditional desktop computers, the ACEMAGIC F5A AI 470 demonstrates that compact size doesn't have to mean compromising on processing power or connectivity options. With its Ryzen AI HX 470 processor and extensive port selection, it's a compelling option for users who need a powerful yet space-efficient computing solution.
