xTool F2 Ultra Fiber Laser Review: Precision Metal Engraving Redefined

The xTool F2 Ultra Fiber Laser represents a significant leap in desktop laser technology, delivering professional-grade metal engraving capabilities previously unseen in compact systems. With its dual-laser design and precision positioning, this machine bridges the gap between industrial power and workshop accessibility.

Core Specifications

• Lasers: 60W MOPA fiber (metal) + 40W blue diode (non-metals)
• Work Area: 220 × 220 mm (8.6" × 8.6")
• Engraving Speed: 15,000 mm/s via galvo mirrors
• Material Compatibility: Stainless steel, titanium, brass, wood, acrylic, leather
• Dimensions: 294 × 429 × 521 mm (11.57" × 16.88" × 20.51")
• Weight: 21.6 kg (47 lbs)

Performance Highlights

Metal Mastery: The MOPA laser engraves stainless steel with vivid color variations impossible with standard lasers. During testing, it produced detailed jewelry tags in seconds with 0.2mm positional accuracy using dual 48MP cameras.

Cutting Versatility: The diode laser handles diverse materials:

• Cut through 2mm metal and 23mm wood
• Engraved curved surfaces like hip flasks using auto-focus leveling
• Processed delicate earrings in 55 seconds with minimal charring

Design & Safety

Integrated Enclosure: The slide-down cover contains Class 4 laser hazards during operation. Optional accessories like the conveyor require disabling safety protocols.

Control Hub: Features include:

• Corded touch screen for manual focusing and job control
• USB-C/USB-A connectivity
• Emergency stop button
• Removable equipment key for access control

Critical Omission: Safety glasses aren't included despite open-accessory requirements.

Software Experience

xTool Studio replaces previous software with AI-assisted tools:

• Pros: Intuitive interface, useful AI troubleshooting
• Cons: Token system for advanced features, initial tutorial gaps Material presets need expansion, though QR-coded samples auto-load settings.

Real-World Testing

1. Wood Cutting: 3mm basswood reindeer cut in 2 minutes (4 passes @ 40mm/s)
2. Acrylic Engraving: Shakespeare quote etched in 20 seconds
3. Color Metal: Stainless steel samples showed vibrant hues after 3-hour processing
4. Rubber Stamps: Required slow 4-pass engraving (1hr 33min) to prevent scorching

Value Proposition

At $4,999-$8,099 (with accessories), the F2 Ultra targets professionals needing:

• Jewelry-grade metal engraving
• Multi-material capability
• Production-ready speed

Alternatives:

• Portable xTool F1 ($1099)
• Large-format xTool P2 CO2 ($3399)

The F2 Ultra excels where precision meets power, making it ideal for jewelry studios and customization businesses despite its premium cost.
